EbacUSA PD120-D Pool and Spa Dehumidifier 110V 10154GY-US

Dedicated pool and spa humidity control with digital adjustment and flexible installation.

The EbacUSA PD120-D 110V Pool and Spa Dehumidifier, part 10154GY-US, manages moisture from indoor pools and spas with an internal digital humidistat and a two-speed centrifugal fan. Set your desired relative humidity and let the unit regulate operation to maintain it. This listing is specifically for the 110V, single-phase, 60Hz version with R454c refrigerant, not the separate 220V model.

Commercial and Industrial Applications

Pool and spa water continually releases moisture into the surrounding air. The PD120-D provides a dedicated humidity-control solution for these damp indoor spaces, helping manage the conditions that lead to condensation on building surfaces. It can operate as a standalone unit or be installed in a ducted system, allowing the installation to suit the space rather than requiring the dehumidifier to sit directly in the occupied area.

Size the installation for the actual moisture load, room conditions and ventilation requirements. The manufacturer’s effective-volume figure is a reference specification, not a guarantee that every room of that size will receive adequate humidity control.

Performance and Construction

Ebac rates the PD120-D at 120 pints per day at 80°F and 60% relative humidity, and 140 pints per day at 80°F and 80% relative humidity. The 110V version delivers 262 CFM on low fan speed and 492 CFM on high. Moisture collects in the condensate tray and leaves through gravity drainage, while the condenser reheats the outgoing air.

• Adjustable digital humidistat with system status indicators and an internal diagnostics menu.
• Temperature-sensitive reverse-cycle defrost for operation within the published 33°F to 95°F range.
• Easy-to-change cartridge air filter.
• Rotary compressor and two-speed centrifugal fan.
• Enclosed coils in an epoxy-coated, heavy-gauge steel case.
• Remote humidistat and touch-panel interfaces for optional controls.
• Underside runners with predrilled mounting points.

What’s Included

• 1 PD120-D 110V dehumidifier.
• 1 PD120-D 110V owner’s manual.
• 1 six-pin plug.
• 1 length of 3/8-inch inside-diameter PVC tube, 3 meters long.
• 1 Jubilee clip.

Remote humidistats and the remote touch panel are listed as optional accessories, not included box contents.

Why Choose the PD120-D?

The PD120-D combines local digital humidity control, two airflow settings and standalone or ducted operation for a permanent pool or spa installation. Its status indicators and diagnostics menu make operating information accessible, while optional remote interfaces provide flexibility when the unit is positioned away from the control location. A cartridge filter and defined gravity-drain connection support routine maintenance planning.
