Compare VacuMaid Central Vacuum Units
Scroll down to compare the features and specifications of all VacuMaid Central vacuums sold by eVacuumStore. All products come with free shipping and a generous warranty package. To find out more about a particular model, hover your mouse over the images and double-click to take yourself to the product page.
Light Commercial Unit Spec Sheet | Bag Unit Spec Sheet | Filtered Unit Spec Sheet | Cyclonic Unit Spec Sheet
| VacuMaid Central Vacuum Unit Model: SR14 |
VacuMaid Central Vacuum Unit SR46 |
VacuMaid Central Vacuum Unit SR60 |
VacuMaid Central Vacuum Unit SR64 |
|
 |
 |
 |
 |
 |
| Price | $836.95 | $1049.95 | $1419.95 | $1599.95 |
| Free Shipping | ✔ | ✔ | ✔ | ✔ |
| Manufactured in the USA | ✔ | ✔ | ✔ | ✔ |
| Motor Type | 5.7'' ULTRA Flow Thru | 6.6'' Tangential By-Pass | 8.4'' Tangential By-Pass | 5.7'' Tangential By-Pass |
| 2 Stage Motor | ✔ | ✔ | ✔ | ✔ |
| Voltage | 120 A.C. | 120 A.C. | 120 A.C. | 120 A.C. |
| Amperage | 14.5 | 14.0 | 13.8 | 13.0 |
| Air Watts | 740 | 663 | 713 | 1040 |
| Air Flow | 138 CFM | 139 CFM | 142 CFM | 220 CFM |
| Water Lift | 138 inches | 132 inches | 147 inches | 123 inches |
| Filtration | Cyclonic Inverted Bag Paper Bag Option |
Cyclonic Inverted Bag Paper Bag Option |
Inverted Bag | Inverted Bag |
| Sound Level | 58 dB | 58 dB | 68 dB | 74 dB |
| Dirt Capacity | 27 dry quarts | 27 dry quarts | 38 dry quarts | 38 dry quarts |
| Square Footage | 6,000 sq feet | 9,500 sq feet | 12,000 sq feet | 18,000 sq feet |
| VacuMaid Central Vacuum Unit Model: SR36 |
VacuMaid Central Vacuum Unit SR38 |
VacuMaid Central Vacuum Unit SR52 |
VacuMaid Central Vacuum Unit SR800 |
|
|
 |
 |
 |
 |
| Price | $669.95 | $729.95 | $959.95 | $1269.95 |
| Free Shipping | ✔ | ✔ | ✔ | ✔ |
| Manufactured in the USA | ✔ | ✔ | ✔ | ✔ |
| Motor Type | 5.7'' Flow Thru | 5.7'' ULTRA Flow Thru | 7.2'' Tangential By-Pass | 8.4'' Tangential By-Pass |
| 2 Stage Motor | ✔ | ✔ | ✔ | ✔ |
| Voltage | 120 A.C. | 120 A.C. | 120 A.C. | 120 A.C. |
| Amperage | 11.3 | 14.5 | 15.8 | 13.8 |
| Air Watts | 561 | 740 | 631 | 713 |
| Air Flow | 117 CFM | 138 CFM | 121 CFM | 142 CFM |
| Water Lift | 142 inches | 138 inches | 142 inches | 147 inches |
| Filtration | Sealed Paper Bag | Sealed Paper Bag | Multi-Layer Disposable HEPA Bag |
Multi-Layer Disposable HEPA Bag |
| Sound Level | 58 dB | 58 dB | 70 dB | 68 dB |
| Dirt Capacity | 27 dry quarts | 27 dry quarts | 27 dry quarts | 38 dry quarts |
| Square Footage | 3,000 sq feet | 6,000 sq feet | 10,000 sq feet | 12,000 sq feet |
| VacuMaid Central Vacuum Unit Model: P110 |
VacuMaid Central Vacuum Unit S2400 |
VacuMaid Central Vacuum Unit S1600 |
VacuMaid Central Vacuum Unit S2600 |
VacuMaid Central Vacuum Unit S3600 |
|
|
 |
|
 |
 |
 |
| Price | $999.95 | $1189.95 | $1249.95 | $1499.95 | $2539.95 |
| Free Shipping | ✔ | ✔ | ✔ | ✔ | ✔ |
| Manufactured in the USA | ✔ | ✔ | ✔ | ✔ | ✔ |
| Motor Type | 5.7'' Tangential By-Pass | 7.2'' Tangential By-Pass | 5.7'' Tangential By-Pass | 7.2'' Premier Tangential By-Pass | 7.2'' Premier Tangential By-Pass |
| 2 Stage Motor | ✔ | ✘ | ✔ | ✘ | ✔ |
| Voltage | 120 A.C. | 120 A.C. | 120 A.C. | 120 A.C. | 240 A.C. |
| Amperage | 13.6 | 15.8 | 13.6 | 15.8 | 16.4 |
| Air Watts | 440 | 631 | 440 | 631 | 1268 |
| Air Flow | 112 CFM | 121 CFM | 112 CFM | 121 CFM | 229 CFM |
| Water Lift | 111 inches | 142 inches | 111 inches | 142 inches | 137 inches |
| Filtration | Cyclonic | Cyclonic | Cyclonic | Cyclonic | Cyclonic |
| Sound Level | 75 dB | 66 dB | 61 dB | 60 dB | 78 dB |
| Dirt Capacity | 27 dry quarts | 38 dry quarts | 27 dry quarts | 27 dry quarts | 38 dry quarts |
| Square Footage | 5,000 sq feet | 10,000 sq feet | 5,000 sq feet | 10,000 sq feet | 18,000 sq feet |
